dl50802 (tjc10 series)-edf111壹定发官网登录

specifications
rated voltage	250v ac，dc
rated current	7a ac, dc
contact resistance	20m max
insulation resistance	1000m min
withstand voltage	1500v ac/minute
ambient temperature	-25°c〜 85°c
wire range	awg#24〜#18
materials
receptacle housing	nylon ul94-v0(2)
plug housing	nylon ul94-v0(2)
terminal	phosphor bronze, tin plated
