| 技术特性 | |
| 额定电压 | 50v ac，dc |
| 额定电流 | 1a ac, dc |
| 接触电阻 | 20m max |
| 绝缘电阻 | 100m min |
| 耐压 | 500v ac/minute |
| 环境温度 | -25°c〜 85°c |
| 适用线规 | awg#32〜#28 |
| 材料 | |
| 孔座 | 尼龙ul94-v0(2) |
| smt针座 | lcp ul94-v0 |
| 端子 | 磷青铜,镀锡 |
| 电路 | 类型 | 尺寸(mm) | ||
| a | b | c | ||
| 2 | nh1.0-2ab/2awb | 1.0 | 3.9 | 3.5 |
| 3 | nh1.0-3ab/3awb | 2.0 | 4.9 | 4.5 |
| 4 | nh1.0-4ab/4awb | 3.0 | 5.9 | 5.5 |
| 5 | nh1.0-5ab/5awb | 4.0 | 6.9 | 6.5 |
| 6 | nh1.0-6ab/6awb | 5.0 | 7.9 | 7.5 |
| 电路 | 类型 | 尺寸(mm) | ||
| a | b | c | ||
| 2 | nh1.0-2y(sg/wg) | 1.0 | 3.0 | 2.4 |
| 3 | nh1.0-3y(sg/wg) | 2.0 | 4.0 | 3.4 |
| 4 | nh1.0-4y(sg/wg) | 3.0 | 5.0 | 4.4 |
| 5 | nh1.0-5y(sg/wg) | 4.0 | 6.0 | 5.4 |
| 6 | nh1.0-6y(sg/wg) | 5.0 | 7.0 | 6.4 |
