| 技术特性 | |
| 额定电压 | 250v ac，dc |
| 额定电流 | 3a ac, dc |
| 接触电阻 | 20m max |
| 绝缘电阻 | 1000m min |
| 耐压 | 1000v ac/minute |
| 环境温度 | -25°c〜 85°c |
| 适用线规 | awg#28〜#22 |
| 材料 | |
| 孔座 | 尼龙ul94-v0(2) |
| 针座 | 尼龙ul94-v0(2) |
| 端子 | 磷青铜,镀锡 |
| 电路 | 类型 | 尺寸(mm) | ||
| a | b | |||
| 2×2 | phd-4y | phd-4a(w/d) | 2.00 | 6.00 |
| 2×3 | phd-6y | phd-6a(w/d) | 4.00 | 8.00 |
| 2×4 | phd-8y | phd-8a(w/d) | 6.00 | 10.00 |
| 2×5 | phd-10y | phd-10a(w/d) | 8.00 | 12.00 |
| 2×6 | phd-12y | phd-12a(w/d) | 10.00 | 14.00 |
| 2×7 | phd-14y | phd-14a(w/d) | 12.00 | 16.00 |
| 2×8 | phd-16y | phd-16a(w/d) | 14.00 | 18.00 |
| 2×9 | phd-18y | phd-18a(w/d) | 16.00 | 20.00 |
| 2×10 | phd-20y | phd-20a(w/d) | 18.00 | 22.00 |
| 2×11 | phd-22y | phd-22a(w/d) | 20.00 | 24.00 |
| 2×12 | phd-24y | phd-24a(w/d) | 22.00 | 26.00 |
| 2×13 | phd-26y | phd-26a(w/d) | 24.00 | 28.00 |
| 2×14 | phd-28y | phd-28a(w/d) | 26.00 | 30.00 |
| 2×15 | phd-30y | phd-30a(w/d) | 28.00 | 32.00 |
| 2×16 | phd-32y | phd-32a(w/d) | 30.00 | 34.00 |
| 2×17 | phd-34y | phd-34a(w/d) | 32.00 | 36.00 |
| 2×18 | phd-36y | phd-36a(w/d) | 34.00 | 38.00 |
| 2×19 | phd-38y | phd-38a(w/d) | 36.00 | 40.00 |
| 2×20 | phd-40y | phd-40a(w/d) | 38.00 | 42.00 |
| 2×21 | phd-42y | phd-42a(w/d) | 40.00 | 44.00 |
| - | - | - | - | - |
| 2×23 | phd-46y | phd-46a(w/d) | 44.00 | 48.00 |
